Lawn Tractors > John Deere > 340 Cyclone

John Deere 340 Cyclone



John Deere 340 Cyclone tractor photo
1976 - 1978
Model year
Snowmobile
Series map:
340 Cyclone
440 Cyclone
34.0hp
46.0hp
Production
ManufacturerJohn Deere
Snowmobile
Built in Horicon, Wisconsin, USA
Original price was $1,900 in 1976
John Deere 340 Cyclone Engine
Kioritz 339cc 2-cyl gasoline
Fuel tank6.5 gal
24.6 L
Engine details ...
John Deere 340 Cyclone Power
Engine34 hp
25.4 kW
Mechanical
Tracked
Manual steering
Mechanical disc brakes
Suspensionslide rail
Photos
No photos of the John Deere 340 Cyclone are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Track and Dimensions
Weight405 lbs
183 kg
Length104 inches
264 cm
Width39 inches
99 cm
Height41 inches
104 cm
Track width15.5 inches
39 cm
Electrical
Groundnegative
Battery volts12
References
340 Cyclone references literature
Big John published in 1975, by John Deere
Operator's Manual 340 and 440 Cyclone Snowmobiles (OM-M66119) published in 1975
