Lawn Tractors > John Deere > JDX4

John Deere JDX4



John Deere JDX4 tractor photo
1973 - 1975
Model year
Snowmobile
Series map:
JDX4
JDX8
25.0hp
40.0hp
Production
ManufacturerJohn Deere
Snowmobile
Built in Horicon, Wisconsin, USA
Original price was $1,000 in 1973
John Deere JDX4 Engine
Kohler 291cc 2-cyl gasoline
Fuel tank5.5 gal
20.8 L
Engine details ...
John Deere JDX4 Power
Engine25 hp
18.6 kW
Mechanical
Tracked
Manual steering
Mechanical band brakes
Suspensionbogie wheel
Photos
No photos of the John Deere JDX4 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Track and Dimensions
Weight396 lbs
179 kg
Length103.4 inches
262 cm
Width35.5 inches
90 cm
Height40 inches
101 cm
Track width15.5 inches
39 cm
Electrical
Groundnegative
Battery volts12
References
JDX4 references literature
Nothing Runs Like A Deere published in 1972, by John Deere
Operator's Manual JDX4 and JDX8 Snowmobiles (OM-M63828) published in 1972
