Production | |
Distributor | Craftsman (a part of Sears) |
Manufacturer | Roper |
Garden tractor |
Craftsman 917.25472 Engine | |
18HP Briggs & Stratton 693cc 2-cyl gasoline | |
Fuel tank | 3.5 gal 13.2 L |
Engine details ... |
Craftsman 917.25472 Transmission | |
5-speed gear | |
Transmission details ... |
Mechanical | |
Two-wheel drive | |
Manual steering | |
Mechanical disc brakes | |
Open operator station. |
Photos | |
No photos of the Craftsman 917.25472 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Power Take-off (PTO) | |
Mid PTO | independent |
Clutch | manual |
Mid PTO Type | pulley |
Dimensions & Tires | |
Weight | 515 lbs 233 kg |
Front tire | 15x6.0 |
Rear tire | 20x10.0 |
Full dimensions and tires ... |
Craftsman 917.25472 attachments | |
44" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ... |
Electrical | |
Ground | negative |
Battery volts | 12 |
References | |
Craftsman Lawn and Garden Riding Equipment and Attachments published in 1989, by Sears |
