Craftsman 917.25471 YT 14


Craftsman 917.25471 YT 14 tractor photo
1989
Lawn tractor
Roper built
Production
DistributorCraftsman (a part of Sears)
ManufacturerRoper
Lawn tractor
Craftsman 917.25471 Engine
14HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical disc brakes
Open operator station.
Photos
No photos of the Craftsman 917.25471 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Mid PTO Typepulley
Dimensions & Tires
Weight487 lbs
220 kg
Front tire15x6.00-6
Rear tire18x9.5-8
Full dimensions and tires ...
Craftsman 917.25471 attachments
38" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
917.25471 YT 14 references literature
Craftsman Lawn and Garden Riding Equipment and Attachments published in 1989, by Sears
