Lawn Chief 39003


Lawn Chief 39003 tractor photo
1982
Garden tractor
Murray built

Note: the Lawn Chief model 39003 is the same as the Murray 39003. The following data is from the 39003 listing.
Production
DistributorLawn Chief
ManufacturerMurray
Garden tractor
Lawn Chief 39003 Engine
16HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Disc brakes
Open operator station.
Photos
No photos of the Lawn Chief 39003 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Weight658 lbs
298 kg
Front tire16x6.50
Rear tire23x8.50
Full dimensions and tires ...
Lawn Chief 39003 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
39003 Serial Numbers
198282-39003 (model code)
198383-39003 (model code)
198484-39003 (model code)

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
39003 references literature
Tractors and Rear Engine Riders published in 1982, by Lawn Chief
