Lawn Chief 30502
|
|
Note: the Lawn Chief model 30502 is the same as the Murray 30502. The following data is from the 30502 listing. |
| Production | |
| Distributor | Lawn Chief |
| Manufacturer | Murray |
| Riding lawn mower | |
| Lawn Chief 30502 Engine | |
| 8HP Briggs & Stratton 318cc 1-cyl gasoline | |
 Engine details ... |
| Lawn Chief 30502 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Lawn Chief 30502 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Weight | 329 lbs 149 kg |
| Front tire | 10.00x3.50 |
| Rear tire | 16.00x6.50 |
 Full dimensions and tires ... | |
| Lawn Chief 30502 attachments | |
| 30" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Tractors and Rear Engine Riders published in 1982, by Lawn Chief | |
| Tractors and Rear Engine Riders published in 1985, by Lawn Chief |
