AGCO 1614VH


AGCO 1614VH tractor photo
1997 - 1999
1600 Series
Lawn tractor
Simplicity built

Note: the AGCO model 1614VH is the same as the Simplicity Broadmoor 14H. The following data is from the Broadmoor 14H listing.
Production
DistributorAGCO
ManufacturerSimplicity
Lawn tractor
Variants
Broadmoor 14Hsimilar Simplicity model
AGCO 1614VH Engine
14HP Vanguard 480cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the AGCO 1614VH are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Mid PTO Typepulley
Dimensions & Tires
Wheelbase50.75 inches
128 cm
Weight424 lbs
192 kg
Front tire15x6.0-6
Rear tire20x8.0-8
Full dimensions and tires ...
AGCO 1614VH attachments
38" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
1614VH references literature
Product Guide Fall 1998 published by Simplicity
