AGCO 1312H


No photo available
1990 - 1991
1300 Series
Front-mount mower
Simplicity built
Series map:
1312G
1312H
1313H
12.0hp
12.0hp
12.5hp

Note: the AGCO model 1312H is the same as the Simplicity 12FCH42. The following data is from the 12FCH42 listing.
Production
DistributorAGCO
ManufacturerSimplicity
Front-mount mower
Original price was $3,299 in 1990
Variants
12FCH42similar Simplicity model
AGCO 1312H Engine
12HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank2 gal
7.6 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the AGCO 1312H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase40 inches
101 cm
Weight622 lbs
282 kg
Front tire16x6.5-8
Rear tire13x5.0-6
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps9
Battery CCA200
Battery volts12
References
1312H references literature
Operator's Manual 1300 Series (1707275) published in 1992
