AGCO 1313H


AGCO 1313H tractor photo
1992 - 1994
1300 Series
Front-mount mower
Simplicity built
Series map:
1312H
1313H
1316H
12.0hp
12.5hp
16.0hp

Note: the AGCO model 1313H is the same as the Simplicity 12.5FCH42. The following data is from the 12.5FCH42 listing.
Production
DistributorAGCO
ManufacturerSimplicity
Front-mount mower
Original price$3,900 (1993 )
$3,950 (1994 )
Variants
12.5FCH42similar Simplicity model
AGCO 1313H Engine
12.5HP Briggs & Stratton 480cc 2-cyl gasoline
Fuel tank2 gal
7.6 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase40 inches
101 cm
Weight633 lbs
287 kg
Front tire16x6.5-8
Rear tire13x5.0-6
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps16
Battery CCA200
Battery volts12
References
1313H references literature
Operator's Manual 1300 Series (1707275) published in 1992
Lawn & Garden Tractors published in 1993, by AGCO Allis
Lawn & Garden Tractors published in 1994, by AGCO Allis
1994 Price List published in 1993, by Simplicity
