AGCO 1616H


AGCO 1616H tractor photo
1993 - 2002
Model year
1600 Series
Lawn tractor
Simplicity built

Note: the AGCO model 1616H is the same as the Simplicity Broadmoor 16VH. The following data is from the Broadmoor 16VH listing.
Production
DistributorAGCO
ManufacturerSimplicity
Lawn tractor
AGCO 1616H Engines
16HP Vanguard 480cc 2-cyl gasoline
16HP Briggs & Stratton 655cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the AGCO 1616H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Mid PTO Typepulley
Dimensions & Tires
Wheelbase50.75 inches
128 cm
Weight424 lbs
192 kg
Front tire15x6.0-6
Rear tire20x8.0-8
Full dimensions and tires ...
AGCO 1616H attachments
38" mid-mount mower deck
44" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
1616H references literature
Lawn and Garden Equipment published in 2000, by AGCO
Product Guide Fall 1998 published by Simplicity
