Note: the AGCO model 409G is the same as the Simplicity Coronet 9G. The following data is from the Coronet 9G listing. |
Production | |
Distributor | AGCO |
Manufacturer | Simplicity |
Riding lawn mower | |
Original price | $1,850 (1993 ) |
$1,900 (1994 ) |
AGCO 409G Engine | |
8.5HP Briggs & Stratton 318cc 1-cyl gasoline | |
Fuel tank | 2 gal 7.6 L |
![]() |
AGCO 409G Transmission | |
5-speed gear | |
![]() |
Mechanical | |
Two-wheel drive | |
Manual steering | |
Open operator station with 13-inch seat. |
Photos | |
No photos of the AGCO 409G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Dimensions & Tires | |
Wheelbase | 43 inches 109 cm |
Weight | 387 lbs 175 kg |
Front tire | 13x5.0-6 |
Rear tire | 16x6.5-8 |
![]() |
AGCO 409G attachments | |
30" mid-mount mower deck | |
![]() |
Electrical | |
Ground | negative |
Battery volts | 12 |
References | |
![]() | |
Rider published in 1992, by AGCO | |
Lawn & Garden Tractors published in 1993, by AGCO Allis | |
Lawn & Garden Tractors published in 1994, by AGCO Allis | |
1994 Price List published in 1993, by Simplicity | |
1996 Dealer Prduct Guide published by Simplicity |
