Production | |
Distributor | Craftsman (a part of Sears) |
Manufacturer | AYP |
Garden tractor |
Craftsman 917.25771 Engine | |
18HP Briggs & Stratton 693cc 2-cyl gasoline | |
Fuel tank | 3.5 gal 13.2 L |
Engine details ... |
Craftsman 917.25771 Transmission | |
6-speed gear | |
Transmission details ... |
Mechanical | |
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
No photos of the Craftsman 917.25771 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Tractor hitch | |
Type | sleeve hitch OptOptional |
Power Take-off (PTO) | |
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
Front tire | 16x6.5-8 |
Rear tire | 23x10.5-12 |
Full dimensions and tires ... |
Craftsman 917.25771 attachments | |
44" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ... |
Electrical | |
Ground | negative |
Charging amps | 5 |
Battery volts | 12 |
References | |
Craftsman Lawn and Garden Rding Equipment published in 1994, by Sears |
