Craftsman 917.25771


Craftsman 917.25771 tractor photo
1994
GT6000 Series
Garden tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Garden tractor
Craftsman 917.25771 Engine
18HP Briggs & Stratton 693cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Craftsman 917.25771 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
Craftsman 917.25771 attachments
44" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps5
Battery volts12
References
917.25771 references literature
Craftsman Lawn and Garden Rding Equipment published in 1994, by Sears
