AGCO 1723H


AGCO 1723H tractor photo
2006 - 2009
1700 Series
Garden tractor
Simplicity built
Production
DistributorAGCO
ManufacturerSimplicity
Garden tractor
Variants
2723Hsimilar Massey Ferguson model
YT2350similar Snapper model
Conquest 23/50similar Simplicity model
AGCO 1723H Engine
23HP Vanguard 626cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Differential lockmechanical rear
Steeringmanual
Steeringpower OptOptional
Disc brakes
Open operator station with 18-inch adjustable seat.
Photos
No photos of the AGCO 1723H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase53 inches
134 cm
Weight711 lbs
322 kg
Front tire16x6.5-8
Rear tire23x10.5-12
Full dimensions and tires ...
AGCO 1723H attachments
50" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps16
Battery CCA340
Battery volts12
References
1723H references literature
Lawn and Garden Equipment published in 2009, by AGCO
Operator's Manual Prestige / 1800 / 2800 / 500 Series, Conquest / 1700 / 2700 / 400 Series (1735106) published in 2010
