Massey Ferguson 2523H


Massey Ferguson 2523H tractor photo
2010 - 2013
2500 Series
Lawn tractor
Simplicity built
Production
DistributorMassey Ferguson
ManufacturerSimplicity
Lawn tractor
Variants
Regent 23/46similar Simplicity model
Massey Ferguson 2523H Engine
23HP Kohler 724cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Massey Ferguson 2523H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase50 inches
127 cm
Weight585 lbs
265 kg
Front tire15x6.0-6
Rear tire22x10.0-8
Full dimensions and tires ...
Electrical
Groundnegative
Battery CCA195
Battery volts12
References
2523H references literature
Lawn & Garden Equipment published in 2011, by Massey Ferguson
