Lawn-Boy 52145 RE12e
|
|
| Production | |
| Manufacturer | Lawn-Boy |
| Riding lawn mower | |
| Built in Plymouth, Wisconsin, USA | |
| Variants | |
| R-12 | similar Ford model |
| Lawn-Boy 52145 Engine | |
| 12HP Briggs & Stratton 465cc 1-cyl gasoline | |
| Fuel tank | 0.75 gal 2.8 L |
 Engine details ... | |
| Lawn-Boy 52145 Transmission | |
| 5-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Lawn-Boy 52145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Weight | 440 lbs 199 kg |
| Front tire | 4.10x3.50 |
| Rear tire | 16x6.50 |
 Full dimensions and tires ... | |
| Lawn-Boy 52145 attachments | |
| 30" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Tractors - Riders - Tillers published in 1987, by Lawn-Boy | |
| Riders and Tractors published in 1987, by Lawn-Boy |
