Jacobsen GT14H 34003


Jacobsen GT14H 34003 tractor photo
1981 - 1986
Garden tractor
Series map:
GT12H
GT14H
GT16H
12.0hp
14.0hp
16.0hp
Production
ManufacturerJacobsen
Garden tractor
Jacobsen GT14H Engine
14HP Kohler 513cc 1-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the Jacobsen GT14H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type0 OptOptional
Typesleeve hitch OptOptional
Power Take-off (PTO)
Rear PTOindependent OptOptional
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase46 inches
116 cm
Weight815 lbs
369 kg
Front tire16x6.50-8
Rear tire23x10.50-12
Full dimensions and tires ...
Jacobsen GT14H attachments
42" mid-mount mower deck
snowblower
blade
backhoe
Attachment details ...
Electrical
Groundnegative
Charging amps15
Battery volts12
Battery AH22
References
GT14H 34003 references literature
Operator's Manual Hydro Tractors GT 12H, GT 14H, GT 16H (JA-99021-0)
Consumer Products Catalog published in 1984, by Jacobsen
