John Deere 856



No photo available
1986 - 1998
Lawn tractor
Series map:
756
856
20.0hp
24.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Horicon, Wisconsin, USA
Variants
855utility tractor
856turf mowing tractor
John Deere 856 Engine
24HP Yanmar 994cc 3-cyl diesel
Engine details ...
John Deere 856 Transmission
hydrostatic
Transmission details ...
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Power steering
Wet disc brakes
Two-post ROPS.
Photos
No photos of the John Deere 856 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel4.33 gal
16.4 L
Hydraulic system4.5 gal
17.0 L
Hydraulics
Typeopen center
Capacity4.5 gal
17.0 L
Pressure2050 psi
141.3 bar
Pump flow5.6 gpm
21.2 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)1686 lbs
764 kg
Rear lift (at 24"/610mm)841 lbs
381 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic disc
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2100
Dimensions & Tires
Wheelbase86.7 inches
220 cm
Weight1800 lbs
816 kg
Front tire23x8.50-12
Rear tire33x12.50-15
Full dimensions and tires ...
856 Serial Numbers
Location:Serial number plate on the rear of the tractor, below the PTO shaft.
Electrical
Groundnegative
Charging systemalternator
Charging amps35
Battery CCA491
Battery volts12
References
856 references literature
Operator's Manual 756 and 856 Turf Mower Tractor Unit (OM-M72247) published in 1986*
*Publication contains known errors.
