Craftsman 502.8130
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | Murray |
| Riding lawn mower | |
| Original price was $499 in 1972 | |
| Craftsman 502.8130 Engine | |
| 8HP 305cc 1-cyl gasoline | |
 Engine details ... |
| Craftsman 502.8130 Transmission | |
| 3-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Craftsman 502.8130 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Dimensions & Tires | |
| Weight | 315 lbs 142 kg |
| Front tire | 10.50x3.50 |
| Rear tire | 13x5 |
 Full dimensions and tires ... | |
| Craftsman 502.8130 attachments | |
| 30" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Suburban, Farm and Ranch Catalog published in 1972, by Sears | |
| Spring through Summer Catalog published in 1972, by Sears |
