Gravely 18-H
|
|
| Production | |
| Manufacturer | Gravely (a part of Ariens) |
| Garden tractor | |
| Gravely 18-H Engine | |
| 18HP Kohler 691cc 2-cyl gasoline | |
| Fuel tank | 4.5 gal 17.0 L |
 Engine details ... | |
| Gravely 18-H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the Gravely 18-H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 48.5 inches 123 cm |
| Weight | 870 lbs 394 kg |
| Front tire | 16x6.50-8 |
| Rear tire | 23x10.50-12 |
 Full dimensions and tires ... | |
| Gravely 18-H attachments | |
| 48" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 15 |
| Battery volts | 12 |
| References | |
 | |
| Riding Tractors published in 1990, by Gravely |
