Lawn Tractors > John Deere > X370

John Deere X370



John Deere X370 tractor photo
2016 - 2025
Model year
X300 Series
Lawn tractor
Series map:
X354
X370
X380
21.5hp
21.5hp
23.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Horicon, Wisconsin, USA
Original price was $4,299 in 2021
John Deere X370 Engine
21.5HP Kawasaki 726cc 2-cyl gasoline
Fuel tank3.3 gal
12.5 L
Engine details ...
John Deere X370 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Power steering
Wet disc brakes
Open operator station.
Photos
No photos of the John Deere X370 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase49.4 inches
125 cm
Weight496 lbs
224 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
John Deere X370 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
X370 Serial Numbers
Location:Serial number decal on the right side of the tractor frame, above the front axle.
2021110001
2022130001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps12
Battery CCA340
Battery volts12
References
X370 references literature
Riding Lawn Tractors published in 2021, by John Deere
Riding Lawn Tractors published in 2022, by John Deere
Operator's Manual X300 Tractors (OMUC26545) published in 2020
