John Deere X350R
|
|
| Production | |
| Manufacturer | John Deere |
| Rear-discharge mower | |
| Built in Horicon, Wisconsin, USA | |
| Original price was $4,699 in 2021 | |
| John Deere X350R Engine | |
| 21.5HP Kawasaki 726cc 2-cyl gasoline | |
| Fuel tank | 2 gal 7.6 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Wet disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the John Deere X350R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 49.4 inches 125 cm |
| Front tire | 15x6.00-6 |
| Rear tire | 20x10.00-8 |
 Full dimensions and tires ... | |
| John Deere X350R attachments | |
| 42" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| X350R Serial Numbers | |
| Location: | Serial number decal on the right side of the tractor frame, above the front axle. |
| 2021 | 110001 |
| 2022 | 130001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | flywheel alternator |
| Charging amps | 12 |
| Battery CCA | 340 |
| Battery volts | 12 |
| References | |
 | |
| Riding Lawn Tractors published in 2021, by John Deere | |
| Riding Lawn Tractors published in 2022, by John Deere |
