John Deere X350


John Deere X350 tractor photo
2016 - 2025
Model year
X300 Series
Lawn tractor
Series map:
X330
X350
X354
22.0hp
21.5hp
21.5hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Horicon, Wisconsin, USA
Original price$3,399 (2021 42” )
$3,799 (2021 48” )
Variants
X3502-wheel steering
X3544-wheel steering
X350Rrear-discharge
John Deere X350 Engine
21.5HP Kawasaki 726cc 2-cyl gasoline
Fuel tank3.3 gal
12.5 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Wet disc brakes
Open operator station.
Photos
No photos of the John Deere X350 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase49.4 inches
125 cm
Weight468 lbs
212 kg
Front tire15x6.00-6
Rear tire20x10.00-8
Full dimensions and tires ...
John Deere X350 attachments
42" mid-mount mower deck
48" mid-mount mower deck
snowblower
blade
Attachment details ...
X350 Serial Numbers
Location:Serial number decal on the right side of the tractor frame, above the front axle.
2021110001
2022130001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps12
Battery CCA340
Battery volts12
References
X350 references literature
Riding Lawn Tractors published in 2021, by John Deere
Riding Lawn Tractors published in 2022, by John Deere
Operator's Manual X300 Tractors (OMUC26545) published in 2020
