John Deere X147R
|
|
| Production | |
| Manufacturer | John Deere |
| Rear-discharge mower | |
| Built in Greeneville, Tennessee, USA | |
| John Deere X147R Engine | |
| 12.6KW Briggs & Stratton 655cc 2-cyl gasoline | |
| Fuel tank | 2 gal 7.6 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the John Deere X147R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Weight | 527 lbs 239 kg |
| Front tire | 15x6-6 |
| Rear tire | 18x18.5-8 |
 Full dimensions and tires ... | |
| John Deere X147R attachments | |
| 91 cm mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 9 |
| Battery volts | 12 |
| Battery Group | U1 |
| References | |
 | |
| Lawn Care Solutions published in 2020, by John Deere | |
| Operator's Manual X117R, X147R and X167R (OMUC22606) published in 2020 |
