Lawn Tractors > John Deere > X117R

John Deere X117R



John Deere X117R tractor photo
2021 -
X100 Series
Rear-discharge mower
Series map:
X117R
X147R
10.8kw
12.6kw
Production
ManufacturerJohn Deere
Rear-discharge mower
Built in Greeneville, Tennessee, USA
John Deere X117R Engine
10.8KW Briggs & Stratton 499cc 1-cyl gasoline
Fuel tank2 gal
7.6 L
Engine details ...
John Deere X117R Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the John Deere X117R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Weight516 lbs
234 kg
Front tire15x6-6
Rear tire18x18.5-8
Full dimensions and tires ...
John Deere X117R attachments
91 cm mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging amps9
Battery volts12
Battery GroupU1
References
X117R references literature
Lawn Care Solutions published in 2020, by John Deere
Operator's Manual X117R, X147R and X167R (OMUC22606) published in 2020
