Craftsman 917.25671
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | AYP |
| Lawn tractor | |
| Craftsman 917.25671 Engine | |
| 18HP Kohler 674cc 2-cyl gasoline | |
| Fuel tank | 3.5 gal 13.2 L |
 Engine details ... | |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Craftsman 917.25671 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Front tire | 15x6.0-6 |
| Rear tire | 20x10-8 |
 Full dimensions and tires ... | |
| Craftsman 917.25671 attachments | |
| 46" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 15 |
| Battery CCA | 240 |
| Battery volts | 12 |
| Battery AH | 30 |
| Battery Group | U1R |
| References | |
 | |
| Craftsman Lawn and Garden Tractors published in 1996, by Sears |
