Ariens RM1130 927032
|
|
| Production | |
| Manufacturer | Ariens |
| Riding lawn mower | |
| Built in Brillion, Wisconsin, USA | |
| Ariens RM1130 Engine | |
| 11HP Briggs & Stratton 399cc 1-cyl gasoline | |
| Fuel tank | 0.75 gal 2.8 L |
 Engine details ... | |
| Ariens RM1130 Transmission | |
| 6-speed fiction disc | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station. |
| Photos | |
| No photos of the Ariens RM1130 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | idler pulley |
| Dimensions & Tires | |
| Wheelbase | 45.5 inches 115 cm |
| Weight | 375 lbs 170 kg |
| Front tire | 4.10-3.50x4 |
| Rear tire | 16-6.50x8 |
 Full dimensions and tires ... | |
| Ariens RM1130 attachments | |
| 30" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Mowers - Tractors - Tillers published in 1987, by Ariens | |
| Tractors published in 1988, by Ariens |
