Lawn Tractors > Toro > 13-38HXL

Toro 13-38HXL



No photo available
1994 - 1996
Lawn tractor
Production
ManufacturerToro
Lawn tractor
Toro 13-38HXL Engine
13HP Briggs & Stratton 1-cyl gasoline
Engine details ...
Toro 13-38HXL Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Toro 13-38HXL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Front tire15x6-6
Rear tire18x9.50-8
Full dimensions and tires ...
Toro 13-38HXL attachments
36" mid-mount mower deck
blade
Attachment details ...
13-38HXL Serial Numbers
Location:Serial number plate on top of the rear fender deck, below the seat.
Electrical
Groundnegative
Battery CCA160
Battery volts12
References
13-38HXL references literature
13-38HXL Lawn Tractor (3316-395) published in 1994
1338HXL Lawn Tractor (3316-974) published in 1994
