Toro Wheel Horse 314-H
|
|
| Production | |
| Manufacturer | Toro |
| Garden tractor | |
| Toro 314-H Engine | |
| 14HP Kohler 512cc 1-cyl gasoline | |
| Fuel tank | 4.25 gal 16.1 L |
 Engine details ... | |
| Toro 314-H Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Open operator station. |
| Photos | |
 | |
 Toro 314-H photos... | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Wheelbase | 45.5 inches 115 cm |
| Weight | 622 lbs 282 kg |
| Front tire | 15x6.00-6 |
| Rear tire | 23x9.50-12 |
 Full dimensions and tires ... | |
| Toro 314-H attachments | |
| 36" mid-mount mower deck | |
| 42" mid-mount mower deck | |
| 48" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| 314-H Serial Numbers | |
| Location: | Serial number decal on the tractor's rear fender deck, below the seat. Model codes shown. |
| 1993 | 73401 |
| 1994 | 73401 |
| 1995 | 73401 |
| 1996 | 73401/73403 |
| 1997 | 73403 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Lawn and Garden Tractors published in 1996, by Toro | |
| Wheel Horse 300/400-Series Hydro Garden Tractors (3315-390) published in 1993 | |
| Wheel Horse 314H Garden Tractor (3318-531) published in 1996 |
