Craftsman 917.25589
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | AYP |
| Garden tractor | |
| Original price was $2,099 in 1993 | |
| Craftsman 917.25589 Engine | |
| 18HP Briggs & Stratton 693cc 2-cyl gasoline | |
| Fuel tank | 3.5 gal 13.2 L |
 Engine details ... | |
| Craftsman 917.25589 Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station. |
| Photos | |
| No photos of the Craftsman 917.25589 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Weight | 665 lbs 301 kg |
 Full dimensions and tires ... | |
| Craftsman 917.25589 attachments | |
| 44" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 3 (battery) |
| 5 (headlights) | |
| Battery volts | 12 |
| References | |
 | |
| Lawn & Garden Catalog published in 1993, by Sears | |
| 1993 Spring/Summer Annual published by Sears |
