Deutz-Allis Vanguard FC12H


Deutz-Allis Vanguard FC12H tractor photo
1988 - 1989
Vanguard Series
Front-mount mower
Simplicity built

Note: the Deutz-Allis model Vanguard FC12H is the same as the Simplicity SunRunner 12H. The following data is from the SunRunner 12H listing.
Production
DistributorDeutz-Allis
ManufacturerSimplicity
Front-mount mower
Deutz-Allis Vanguard FC12H Engine
12HP Briggs & Stratton 465cc 1-cyl gasoline
Fuel tank2 gal
7.6 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the Deutz-Allis Vanguard FC12H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchmechanical ilder pulley
Dimensions & Tires
Wheelbase40 inches
101 cm
Weight529 lbs
239 kg
Front tire15x6-6.00
Rear tire4.1/3.5-4
Full dimensions and tires ...
Deutz-Allis Vanguard FC12H attachments
36" front-mount mower deck
42" front-mount mower deck
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
Vanguard FC12H references literature
Lawn & Garden Riding Equipment published in 1988, by Deutz-Allis
Operator's Manual FC1242H (1701134) published in 1987
Vanguard published in 1986, by Deutz-Allis
