John Deere X590


John Deere X590 tractor photo
2016 -
Select X500 Series
Garden tractor
Series map:
X584
X590
24.0hp
25.5hp
Production
ManufacturerJohn Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price was $7,899 in 2017 with 54-inch
John Deere X590 Engine
25.5HP Kawasaki 726cc 2-cyl gasoline
Fuel tank4.4 gal
16.7 L
Engine details ...
Mechanical
Two-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Open operator station. Canopy and weather cab optional.
Tractor hitch
Typesleeve hitch OptOptional
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase51.2 inches
130 cm
Weight654 lbs
296 kg
Front tire16x6.5-8
Rear tire24x12-12
Full dimensions and tires ...
John Deere X590 attachments
48" mid-mount mower deck
54" mid-mount mower deck
snowblower
blade
Attachment details ...
X590 Serial Number Location
John Deere X590 serial number location
Serial number on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery CCA500
Battery volts12
References
X590 references literature
Riding Lawn Tractors published in 2015, by John Deere
The Complete Range of Lawn Care Solutions published in 2016, by John Deere
Riding Lawn Tractors published in 2017, by John Deere
Riding Lawn Tractors published in 2019, by John Deere
Riding Lawn Tractors published in 2016, by John Deere
Lawn Care Solutions published in 2020, by John Deere
Riding Lawn Tractors published in 2021, by John Deere
Riding Lawn Tractors published in 2022, by John Deere
