Ariens High Sierra 2248 934027
Series map:
High Sierra 2248
22.0hp
| Production |
| Manufacturer | Ariens
|
| Lawn tractor |
| Built in Brillion, Wisconsin, USA |
| Original price was $4,909 in 2000 |
| Mechanical |
| Two-wheel drive |
| Manual steering |
| Disc brakes |
| Open operator station. |
| Power Take-off (PTO) |
| Mid PTO | independent
|
| Clutch | electric
|
| High Sierra 2248 Serial Number Location |
 |
| Serial number plate on the left side of the 2248 frame, just ahead of the rear tire. |
| Electrical |
| Ground | negative
|
| Charging amps | 16
|
| Battery CCA | 220
|
| Battery volts | 12
|
| References |
 |
| Yard Tractors published in 2001, by Ariens |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on April 15, 2016 |
