John Deere E90
|
|
| Production | |
| Manufacturer | John Deere |
| Riding lawn mower | |
| John Deere E90 Engine | |
| 0.9HP electric | |
 Engine details ... |
| John Deere E90 Transmission | |
| 3-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station |
| Photos | |
 | |
 John Deere E90 photos... | |
| Dimensions & Tires | |
| Wheelbase | 40 inches 101 cm |
| Weight | 475 lbs 215 kg |
| Front tire | 11x4.00-5 |
| Rear tire | 16x16.50-8 |
 Full dimensions and tires ... | |
| John Deere E90 attachments | |
| 34" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| E90 Serial Numbers | |
| Location: | Serial number plate on right rear of mower. |
| 1972 | 001001 |
| 1973 | 010001 |
| 1974 | 011705 |
FAQ: How to read a serial number table. | |
| Questions | |
| Hello I am looking for information on how to get my mower running it is a jd e90 from 1972 I don't have any batteries for it so could we start there. What kind should I put in it?
John Deere part number TY6115 is the current battery, a replacement for the original AM33995. | |
| Email: Peter@TractorData.com |
| References | |
 | |
| New John Deere Electric Riding Mower published in 1971 | |
| New John Deere Electric Riding Mower published in 1972 | |
| Riding Mowers published in 1975, by John Deere | |
| Service Manual John Deere Electric 90 Mower (SM-2098) published in 1973 |
