Lawn Tractors > John Deere > SRX75

John Deere SRX75 Engine



John Deere SRX75 tractor photo
1991 - 1996
Riding lawn mower
Series map:
SRX75
SRX95
9.0hp
12.5hp
Engine Detail
Kawasaki FC290V
gasoline
1-cylinder
air-cooled vertical-shaft
Displacement290 cc
17.7 ci
Bore/Stroke3.07x2.36 inches
78 x 60 mm
Power9 hp
6.7 kW
Air cleanerdry element
Idle RPM1550-3350
Starterelectric
Starter volts12
Oil capacity1.16 qts
1.1 L
