Power King 2416
|
|
| Production | |
| Manufacturer | Power King (a part of Engineering Products Company) |
| Garden tractor | |
| Built in Waukesha, Wisconsin, USA | |
| Power King 2416 Engine | |
| 16HP Briggs & Stratton 531cc 1-cyl gasoline | |
 Engine details ... |
| Power King 2416 Transmissions | |
| 3-speed gear | |
| 4-speed gear | |
| 9-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Final drives | bull gear |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. Vinyl weather cab optional. | |
| Photos | |
| No photos of the Power King 2416 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 3 gal 11.4 L |
| Hydraulic system | 5 gal 18.9 L |
| Hydraulics | |
| Type | open center |
| Capacity | 5 gal 18.9 L |
| Pressure | 1000 psi 69.0 bar |
| Pump flow | 1.7 gpm 6.4 lpm |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Clutch | electro-magnetic |
| Rear PTO Type | 2000 |
| Front PTO | independent |
| Clutch | electro-magnetic |
| Dimensions & Tires | |
| Wheelbase | 54.375 inches 138 cm |
| Weight | 1058 to 1075 pounds |
| Front tire | 4.00-12 |
| Rear tire | 8.30-24 |
 Full dimensions and tires ... | |
| Power King 2416 attachments | |
| 48" mid-mount mower deck | |
| 60" mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
 Attachment details ... |
| 2416 Serial Number Location | |
 | |
| Serial number decal on tractor dashboard and on the front of the hood. |
| 2416 Serial Numbers | |
| 1978 | 43827 |
| 1979 | 78142 |
| 1980 | 52590 |
| 1981 | 55832 |
| 1982 | 57908 |
| 1983 | 59796 |
| 1984 | 61552 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | flywheel alternator |
| Charging amps | 15 |
| Battery volts | 12 |
| References | |
 | |
| Power King - One Tough Tractor published in 1980, by EPCO |
