Bolens G11XL 1060


Bolens G11XL 1060 tractor photo
1978 - 1981
Medium Frame XL Series
Garden tractor
Production
ManufacturerBolens
Garden tractor
Variants
G11XLgear drive
H11XLhydrostatic
Bolens G11XL Engine
11HP Briggs & Stratton 399cc 1-cyl gasoline
Fuel tank1.6 gal
6.1 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Mechanical band brakes
Open operator station. Vinyl soft-side cab optional.
Photos
No photos of the Bolens G11XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Typesleeve hitch
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Front PTO Type3600 (pulley)
Dimensions & Tires
Wheelbase49 inches
124 cm
Weight760 lbs
344 kg
Front tire16x6.50-8
Rear tire23x8.50-12
Full dimensions and tires ...
Bolens G11XL attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
Battery AH45
References
G11XL 1060 references literature
Lawn and Garden Tractors published in 1977, by Bolens
Lawn and Garden Tractors published in 1978, by Bolens
Lawn Machines published in 1981, by Bolens
