Lawn Tractors > John Deere > X754

John Deere X754



John Deere X754 tractor photo
2013 -
X700 Series
Garden tractor
Series map:
X750
X754
X758
24.0hp
24.0hp
24.0hp
Production
ManufacturerJohn Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price$11,499 (2013 )
$11,669 (2018 )
$12,069 (2019 )
Variants
X7484WD 2-wheel steer
X7442WD 4-wheel steer
X7402WD 2-wheel steer
John Deere X754 Engine
24HP Yanmar 993cc 3-cyl diesel
Fuel tank5.2 gal
19.7 L
Engine details ...
John Deere X754 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Power four-wheel steering
Internal wet disc brakes
Open operator station with tilt-back seat. Optional hard cab.
Photos
No photos of the John Deere X754 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type0 OptOptional
 1-limited OptOptional
Power Take-off (PTO)
Rear PTOindependent OptOptional
Rear PTO Type540
Front PTOindependent
Clutchelectro-hydraulic
Dimensions & Tires
Wheelbase54.5 inches
138 cm
Weight995 lbs
451 kg
Front tire18x7.00-8
Rear tire26x10.50-12
Full dimensions and tires ...
John Deere X754 attachments
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
snowblower
Attachment details ...
X754 Serial Number Location
John Deere X754 serial number location
Serial number plate on the right side of the tractor frame, below the footrest.
X754 Serial Numbers
2013010001
2014020001
2015030001
2016040001
2017050001
2018060001
2019070001
2020080001
2021090001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemregulated
Charging amps40
Battery volts12
References
X754 references literature
The Complete Range of Lawn Care Solutions published in 2016, by John Deere
Riding Lawn Tractors published in 2021, by John Deere
Riding Lawn Tractors published in 2022, by John Deere
Operator's Manual X750, X754, X758 (OMM166906) published in 2012
Operator's Manual X750, X754, X758 (OMUC29404) published in 2021
Signature Series published in 2013, by John Deere
Signature Series published in 2016, by John Deere
Signature Series published in 2018, by John Deere
