John Deere X734
| | 2013 - |
| X700 Series | | Garden tractor |
|
Series map:
X730
X734
X738
25.5hp
25.5hp
25.5hp
| Production |
| Manufacturer | John Deere
|
| Garden tractor |
| Built in Horicon, Wisconsin, USA |
| Original price | $10,299 (2013 )
|
| $10,449 (2018 )
|
| $10,849 (2019 )
|
| Variants |
| X739 | 4WD 4-wheel steer
|
| X738 | 4WD 2-wheel steer
|
| X734 | 2WD 4-wheel steer
|
| X730 | 2WD 2-wheel steer
|
| Mechanical |
| Two-wheel drive |
| Steering | hydrostatic power four-wheel steering
|
| Internal wet disc brakes |
| Open operator station with tilt-back seat. Optional hard cab. |
| Tractor hitch |
| Rear Type | 0 (optional)
|
| | 1-limited (optional)
|
| Power Take-off (PTO) |
| Rear PTO | independent (optional)
|
| Rear PTO Type | 540
|
| Front PTO | independent
|
| Clutch | electro-hydraulic
|
| X734 Serial Number Location |
 |
| Serial number plate on the right side of the tractor frame, below the footrest. |
| Electrical |
| Ground | negative
|
| Charging system | regulated
|
| Charging amps | 20
|
| Battery volts | 12
|
| References |
 |
| Riding Lawn Tractors published in 2021, by John Deere |
| Riding Lawn Tractors published in 2022, by John Deere |
| Signature Series published in 2013, by John Deere |
| Signature Series published in 2016, by John Deere |
| Signature Series published in 2018, by John Deere |
| Operator's Manual X710, X730, X734, X738, X379 (OMM166905) published in 2012 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on December 13, 2021 |
