Engine Detail | |
Briggs & Stratton 401417 | |
gasoline | |
2-cylinder | |
air-cooled horizontal-shaft opposed-twin | |
Displacement | 655 cc 40 ci |
Bore/Stroke | 3.4375x2.156 inches 87 x 55 mm |
Power (gross) | 16 hp 11.9 kW |
Fuel system | downdraft carburetor with integral fuel pump |
Air cleaner | dry with pre-cleaner |
Torque | 25.8 lb-ft 35.0 Nm |
Torque RPM | 2600 |
Starter | electric |
Starter volts | 12 |
Sparkplug | Champion RJ-8 |
Sparkplug gap | 0.030 inches 0.762 mm |
Point gap | 0.020 inches 0.508 mm |
Engine Oil | |
Oil capacity | 1.75 qts 1.7 L |
Oil change | 30 h |
