Lawn Tractors > Cub Cadet > 1517

Cub Cadet 1517



Cub Cadet 1517 tractor photo
2002
1500 Series
Lawn tractor
Series map:
1515
1517
15.0hp
17.0hp
Production
ManufacturerCub Cadet (a part of MTD)
Lawn tractor
Original price was $2899 in 2002
Cub Cadet 1517 Engine
17HP Kohler 1-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Cub Cadet 1517 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Steeringmanual
Dry disc brakes
Open operator station.
Photos
No photos of the Cub Cadet 1517 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase47 inches
119 cm
Weight504 lbs
228 kg
Front tire15x6
Rear tire20x9
Full dimensions and tires ...
Cub Cadet 1517 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery CCA270
Battery volts12
