John Deere X500
| | 2006 - 2015 |
|
| Select X500 Series | | Garden tractor |
|
Series map:
X500
X530
26.0hp
26.0hp
| Production |
| Manufacturer | John Deere
|
| Garden tractor |
| Built in Horicon, Wisconsin, USA |
| Original price was $5,700 in 2011 |
| Mechanical |
| Two-wheel drive |
| Differential lock | mechanical rear
|
| Steering | manual
|
| Open operator station with 15-inch seat and 7-inch adjustment. Cupholder, toolbox, and 12-volt outlet standard. |
| Photos |
| No photos of the John Deere X500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Tractor hitch |
| Type | sleeve hitch
|
| Power Take-off (PTO) |
| Mid PTO | independent
|
| Clutch | electric
|
| X500 Serial Numbers |
| Location: | Front-right of main tractor frame, above front axle.
|
| 2006 | 010001
|
| 2007 | 020001
|
| 2008 | 030001
|
| 2009 | 040001
|
| 2010 | 050001
|
| 2011 | 060001
|
| 2012 | 070001
|
| 2013 | 080001
|
| 2014 | 090001
|
| 2015 | 100001
|
FAQ: How to read a serial number table.
|
| Electrical |
| Ground | negative
|
| Battery CCA | 500
|
| Battery volts | 12
|
| References |
 |
| Riding Lawn Tractors published in 2015, by John Deere |
| Select Series Tractors published in 2012, by John Deere |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 23, 2021 |
