John Deere D120
| | 2011 - 2012 |
| D100 Series | | Lawn tractor |
|
Series map:
D110
D120
D125
19.5hp
21.0hp
20.0hp
| Production |
| Manufacturer | John Deere
|
| Lawn tractor |
| Built in Greeneville, Tennessee, USA |
| Original price was $1,799 in 2011 |
| Mechanical |
| Two-wheel drive |
| Manual steering |
| Mechanical shoe on transaxle brakes |
| Open operator station. Adjustable 15-inch tall seat with 5.5-inches of travel in ten positions. Fender-mounted cup holder. Optional nylon sunshade canopy or snow enclosure. |
| Power Take-off (PTO) |
| Mid PTO | manual independent
|
| D120 Serial Numbers |
| Location: | Serial number on rear of tractor, left side, under fender.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 9
|
| Battery volts | 12
|
| Battery Group | U1
|
| References |
 |
| Operator's Manual D100 Series (OMGX24147) published in 2011 |
| Operator's Manual D100 Series (OMGX24230) published in 2012 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on April 19, 2023 |
