John Deere X304



John Deere X304 tractor photo
2006 - 2015
Model year
Select X300 Series
Lawn tractor
Series map:
X300
X304
X310
18.5hp
18.5hp
18.5hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Horicon, Wisconsin, USA
Variants
X300manual two-wheel steer
X304manual four-wheel steer
X310power two-wheel steer
John Deere X304 Engine
18.5HP Kawasaki 603cc 2-cyl gasoline
Fuel tank3.3 gal
12.5 L
Engine details ...
John Deere X304 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual four-wheel steering
Open operator station. Optional sunshade and vinyl weather enclosure. Adjustable seat with seven inches of travel. Cupholder and tool tray standard.
Photos
No photos of the John Deere X304 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase49.4 inches
125 cm
Weight540 lbs
244 kg
Front tire15x5-6
Rear tire20x10-10
Full dimensions and tires ...
John Deere X304 attachments
42" mid-mount mower deck
snowblower
blade
Attachment details ...
X304 Serial Number Location
John Deere X304 serial number location
Serial number decal on the right side of the tractor frame, above the front axle.
X304 Serial Numbers
2006010001
2007040001
2008085001
2009120001
2010150001
2011180001
2012220001
2013250001
2014280001
2015310001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging amps15
Battery CCA160
Battery volts12
References
X304 references literature
Walk Behind Mower & Lawn Tractor Range published in 2011, by John Deere
The Complete Range of Lawn Care Solutions published in 2014, by John Deere
Riding Lawn Tractors published in 2015, by John Deere
Select Series Tractors published in 2012, by John Deere
X304 manuals literature
Operator's Manual X300 Tractors (OMM163031) published in 2010
Operator's Manual X300 Tractors (OMM164717) published in 2012
Operator's Manual X300 Tractors (OMM167789) published in 2012
Operator's Manual X300 Tractors (OMM173266) published in 2014
