Craftsman 917.27686


No photo available
2006
FS5500 Series
Lawn tractor
AYP built
Series map:
917.27684
917.27686
917.27688
24.0hp
24.0hp
26.0hp
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.27686 Engine
24HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Steeringmanual
Open operator station.
Photos
No photos of the Craftsman 917.27686 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Electrical
Groundnegative
Charging amps16
Battery CCA280
Battery volts12
Battery AH35
Battery GroupU1R
References
917.27686 references literature
2006 Riding Equipment published by Sears
