Craftsman 917.27361


Craftsman 917.27361 tractor photo
2004
DYT 4000 Series
Lawn tractor
AYP built
Production
DistributorCraftsman (a part of Sears)
ManufacturerAYP
Lawn tractor
Craftsman 917.27361 Engine
24HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station
Photos
No photos of the Craftsman 917.27361 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Front tire15x6.0-6
Rear tire20x10.8
Full dimensions and tires ...
Electrical
Groundnegative
Charging amps15
Battery CCA280
Battery volts12
Battery AH35
Battery GroupU1R
References
917.27361 references literature
2004 Riding Equipment published by Sears
