Craftsman 917.27375
|
|
| Production | |
| Distributor | Craftsman (a part of Sears) |
| Manufacturer | AYP |
| Lawn tractor | |
| Craftsman 917.27375 Engine | |
| 18HP Briggs & Stratton 503cc 1-cyl gasoline | |
| Fuel tank | 1.25 gal 4.7 L |
 Engine details ... | |
| Craftsman 917.27375 Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Open operator station |
| Photos | |
| No photos of the Craftsman 917.27375 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | manual |
| Dimensions & Tires | |
| Front tire | 15x6.0-6 |
| Rear tire | 20x10-8 |
 Full dimensions and tires ... | |
| Craftsman 917.27375 attachments | |
| 42" mid-mount mower deck | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 3 (battery) |
| 5 (headlights) | |
| Battery CCA | 230 |
| Battery volts | 12 |
| Battery AH | 28 |
| Battery Group | U1R |
| References | |
 | |
| 2004 Riding Equipment published by Sears |
