Production | |
Manufacturer | Gravely (a part of Ariens) |
Garden tractor |
Gravely 8163-G Engine | |
16HP Briggs & Stratton 1-cyl gasoline | |
Engine details ... |
Gravely 8163-G Transmission | |
8-speed gear | |
Transmission details ... |
Mechanical | |
Two-wheel drive | |
Manual steering | |
Mechanical band brakes | |
Open operator station. |
Photos | |
Gravely 8163-G photos... |
Capacity | |
Fuel | 5.3 gal 20.1 L |
Hydraulic system | 0.25 gal 0.9 L |
Hydraulics | |||
Capacity | 0.25 gal 0.9 L | ||
Oil type |
|
Power Take-off (PTO) | |
Mid PTO | independent |
Dimensions & Tires | |
Wheelbase | 52.25 inches 132 cm |
Weight | 829 to 865 pounds |
Front tire | 16x6.50-8 |
Rear tire | 23x8.50-12 |
Full dimensions and tires ... |
Gravely 8163-G attachments | |
40" mid-mount mower deck | |
50" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ... |
8163-G Serial Numbers | |
Location: | Under hood on right side, on instrument panel support frame. |
Electrical | |
Ground | negative |
Battery volts | 12 |
Battery AH | 42 |
Battery Group | BCI 22F |
References | |
Riding Tractors published in 1986, by Gravely |
