Snapper GT600
|
|
| Production | |
| Manufacturer | Snapper (a part of Briggs & Stratton) |
| Garden tractor | |
| Original price was $12,095 in 2009 | |
| Variants | |
| SGT2754 | 54-inch deck |
| SGT2760 | 60-inch deck |
| SGT2772 | 72-inch deck |
| Legacy XL 27D | similar Simplicity model |
| Snapper GT600 Engine | |
| 27HP Vanguard 952cc 3-cyl diesel | |
| Fuel tank | 5.5 gal 20.8 L |
 Engine details ... | |
| Snapper GT600 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Drive | 4x4 4WD |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Open operator station with 18-inch high back seat. | |
| Photos | |
| No photos of the Snapper GT600 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 300 psi 20.7 bar |
| Pump flow | 5 gpm 18.9 lpm |
| Tractor hitch | |
| Rear Type | I (limited) |
| Rear lift (at 24"/610mm) | 300 lbs 136 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 58.5 inches 148 cm |
| Weight | 1131 lbs 513 kg |
| Front tire | 18x8.50-8 |
| Rear tire | 26x12.00-12 |
 Full dimensions and tires ... | |
| Snapper GT600 attachments | |
| 54" mid-mount mower deck | |
| 60" mid-mount mower deck | |
| 72" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 40 |
| Battery CCA | 500 |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual GT600 Series (1733761) published in 2007 |
