John Deere 345
| | 1995 - 2001 |
|
| 300 Series | | Garden tractor |
|
Series map:
335
345
355D
20.0hp
18.0hp
18.0hp
| Production |
| Manufacturer | John Deere
|
| Garden tractor |
| Built in Horicon, Wisconsin, USA |
| Original price was $7,295 in 1995 |
| Mechanical |
| Two-wheel drive |
| Power steering |
| Wet disc brakes |
| Open operator station. Adjustable seat with 7-inches of travel. |
| Tractor hitch |
| Type | sleeve hitch OptOptional
|
| Power Take-off (PTO) |
| Mid PTO | independent
|
| Clutch | electric
|
| 345 Serial Number Location |
 |
| Serial number decal on the rear of the 345, above the drawbar. |
| Electrical |
| Ground | negative
|
| Charging system | flywheel alternator
|
| Charging amps | 17
|
| Battery CCA | 500
|
| Battery volts | 12
|
| Battery Group | 45
|
| References |
 |
| Lawn and Garden Product Information Handbook published in 1996, by John Deere |
| Lawn and Garden Product Information Handbook published in 1997, by John Deere |
| Lawn and Garden Product Information Handbook published in 1998, by John Deere |
| Lawn and Garden Product Information Handbook published in 2000, by John Deere |
| Lawn and Garden Product Information Handbook published in 2001, by John Deere |
| John Deere Lawn and Garden Tractors published in 1995 |
| Lawn and Garden Tractors published in 1998, by John Deere |
| Lawn and Garden Tractors published in 2000, by John Deere |
| Lawn & Grounds Care Sales Manual published in 1997, by John Deere* |
| *Publication contains known errors. |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 30, 2021 |
