John Deere X748



John Deere X748 tractor photo
2006 - 2012
Select X700 Series
Garden tractor
Series map:
X744
X748
X749
24.0hp
24.0hp
24.0hp
Production
ManufacturerJohn Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price was $11,449 in 2011
Variants
X740two-wheel drive
X7442WD, all-wheel steer
X748four-wheel drive
X7494WD, all-wheel steer
X748SEupgraded seat, tires, and brush guard
John Deere X748 Engines
24HP Yanmar 1116cc 3-cyl diesel
24HP Yanmar 904cc 3-cyl diesel
Fuel tank6.5 gal
24.6 L
Engine details ...
John Deere X748 Transmission
hydrostatic
Transmission details ...
Mechanical
Drive4x4 MFWD 4WD (2006-2008)
 4x4 HFWD 4WD (2009-)
Steeringhydrostatic power
Wet disc brakes
Open operator station featuring 18-inch seat with 7-inches of adjustment. Cupholder, toolbox, tilt steering, and 12-volt outlet standard. Optional soft-side or hard cab. Special Edition seat has armrests plus tilt and lumbar adjustment.
Photos
John Deere X748
John Deere X748 photos...
Hydraulics
Pressure924 psi
63.7 bar
Valves2
Total flow6.5 gpm
24.6 lpm
Tractor hitch
Rear Type0 (optional)
 1-Limited (optional)
Power Take-off (PTO)
Rear PTOindependent (optional)
Rear PTO Type540
Mid PTOindependent
Mid PTO Type2000
Front PTOoptional
Front PTO Type2000
Dimensions & Tires
Wheelbase55.7 inches
141 cm
Weight1080 to 1153 pounds
Front tire18x8.5-10
Rear tire26x12-12
Full dimensions and tires ...
John Deere X748 attachments
48" mid-mount mower deck
54" mid-mount mower deck
62" mid-mount mower deck
60" mid-mount mower deck
front-end loader
Attachment details ...
X748 Serial Number Location
John Deere X748 serial number location
Serial number on the center-right of main tractor frame, just behind hydraulic couplers.
X748 Serial Numbers
2006010001
2007020001
2008030001
2009040001
2010050001
2011060001
2012070001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA500
Battery volts12
References
X748 references literature
Select Series Tractors published in 2007, by John Deere
Select Series Tractors published in 2009, by John Deere
Select Series Tractors published in 2012, by John Deere
X700 Series Diesel Mowing Tractors published in 2010, by John Deere
Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere
Riding Lawn Equipment Attachments & Accessories published in 2011, by John Deere
